Congatec COM Express conga-TCA5 User Manual page 54

Pin Row A Pin Row B
A31 GND (FIXED) B31 GND (FIXED)
A32 AC/HDA_BITCLK B32 SPKR
A33 AC/HDA_SDOUT B33 I2C_CK
A34 BIOS_DIS0# B34 I2C_DAT
A35 THRMTRIP# B35 THRM#
A36 USB6- B36 USB7-
A37 USB6+ B37 USB7+
A38 USB_6_7_OC# B38 USB_4_5_OC#
A39 USB4- B39 USB5-
A40 USB4+ B40 USB5+
A41 GND (FIXED) B41 GND (FIXED)
A42 USB2- B42 USB3-
A43 USB2+ B43 USB3+
A44 USB_2_3_OC# B44 USB_0_1_OC#
A45 USB0- B45 USB1-
A46 USB0+ B46 USB1+
A47 VCC_RTC B47 EXCD1_PERST#
A48 EXCD0_PERST# B48 EXCD1_CPPE#
A49 EXCD0_CPPE# B49 SYS_RESET#
A50 LPC_SERIRQ B50 CB_RESET#
A51 GND (FIXED) B51 GND (FIXED)
A52 PCIE_TX5+ * B52 PCIE_RX5+ *
1
A53 PCIE_TX5- * 1 B53 PCIE_RX5- *
A54 GPI0 B54 GPO1
A55 PCIE_TX4+ B55 PCIE_RX4+
Note
Not supported on conga-TCA5
*1
Supported via an assembly option (customized variant).
*2
Copyright © 2017 congatec AG
Pin Row A
A86 RSVD
A87 RSVD
A88 PCIE0_CK_REF+
A89 PCIE0_CK_REF-
A90 GND (FIXED)
A91 SPI_POWER
A92 SPI_MISO
A93 GPO0
A94 SPI_CLK
A95 SPI_MOSI
A96 TPM_PP
A97 TYPE10# *
1
A98 SER0_TX
A99 SER0_RX
A100 GND (FIXED)
A101 SER1_TX
A102 SER1_RX
A103 LID#
A104 VCC_12V
A105 VCC_12V
A106 VCC_12V
A107 VCC_12V
1
1 A108 VCC_12V
A109 VCC_12V
A110 GND (FIXED)
Pin Row B
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 VGA_RED *
2
B90 GND (FIXED)
B91 VGA_GRN * 2
B92 VGA_BLU *
2
B93 VGA_HSYNC * 2
B94 VGA_VSYNC *
2
B95 VGA_I2C_CK * 2
B96 VGA_I2C_DAT * 2
B97 SPI_CS#
B98 RSVD
B99 RSVD
B100 GND (FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND (FIXED)
TA50m10 54/72
