Run the photovoltaic curve.
After set of desired curve, run the photovoltaic analog. The power supply will
change the output voltage and current at 1ms interval to keep the voltage and
current above V/I curve. This speed is enough to meet most trace mechanisms
at maximum power point.
You can set and run local edit curves locally or remotely.
The user-defined 4096-point V/I datasheet can only be set via remote PC, but
can be run locally or remotely.
1.
2.
3.
4.
5.

3.21 Built-in Waveform

IT6500C models have built in DIN40839 waveform, ISO-16750-2 waveform and
ISO21848 Provide for user to execute the test directly.
Menu as below:
Road-Vehicles Vehicle waveform
DIN40839
ISO16750-2
Press [Shift]+ [I-set] (Function) to enter the Menu operation.
Select PV-SIM with Left/Right key and press [Enter] for confirmation.
Select On or Off. Press [Enter] to switch the current curve status as On.
Press [Esc] to exit the main interface, as shown below.
0.00 V 0.00A
0.0W PV-SIM
Press [On/Off] to turn on the power supply output. The power supply will
output corresponding voltage based on the current value.
Evaluation of automotive starting waveform
12V
24V
User-define
d
Off
On
simulate the waveform to verify the anti-interference
performance of the automotive electronics' products.
Short-Drop
Reset-Test
Starting-Pro
file
Copyright© Itech Electronics Co., Ltd.
Select the 12V waveform
Select the 24V waveform
User defined waveform
Disable/Enable the automotive starting
waveform function.
This test simulates the effect when a
conventional fuse element melts in another
circuit
12V
24V Select 12V or 24V waveform
Off
Enable or Disable the Short
On voltage drop function.
This test verifies the reset behavior of the
DUT at different voltage drops. This test is
applicable to equipment with reset function
The minimum supply voltage
Usmin... Usmin
Off
On Enable/Disable this function
This test verifies the behavior of a DUT during
and after cranking.
12V
24V Select 12V or 24V test system
Function and Features
