LV124 LV124 waveform protocol
E-02
E-04
E-05
E-07
E-08
E-09
E-11
Copyright© Itech Electronics Co., Ltd.
T11 -
Load dump waveform
Test A select centralized load dump
Unsuppression
Test B select centralized load dump
suppression
Off Turn on/off load dump
waveform
On
12V Select 12V or 24V voltage
system
24V
Td Pulse width
Un Peak voltage
Us clamping voltage
Transient overvoltage test waveform
Off Turn on / off this funciton
On
LV124 E-04 Jump start test waveform
Off Turn on/off this funciton
On
LV124 E-05 Load dump test waveform
Off Turn on/off this function
On
LV124 E-07 Slow decrease and increase
of the supply voltage test
waveform
Ubmax Start voltage
Ubmin Holding voltage
Ubmin Holding time at Ubmin
Holding Time
Off Turn on/off this function
On
LV124 E-08 Slow decrease, quick
increase of the supply voltage
test waveform
Ubmax Start voltage
Ubmin Holding voltage
Ubmin Holding time at Ubmin
Holding Time
Off Turn on/off this function
On
LV124 E-09 Reset behavior test waveform
Ubmin Holding voltage
Off Turn on/off this function
On
LV124 E-11 Start pulses
Cold-Start Cold start
Normal: normal pulse
Severe: severe pulse
Warm-Start Warm start
Off Turn on/off this function
On
