OLIMEX© 2012
Power-on led
•
3V battery connector
•
Extension port connectors for many of microcontrollers pins
•
PCB: FR-4, 1.5 mm (0,062"), soldermask, silkscreen component print
•
Dimensions: 160x116 mm (6.3x4.6")
•

1.2 Organization

Each section in this document covers a separate topic, organized as follow:
– Chapter 1 is an overview of the board usage and features
– Chapter 2 provides a guide for quickly setting up the board
– Chapter 3 contains the general board diagram and layout
– Chapter 4 describes the component that is the heart of the board: the STM32F207ZET6
microcontroller
– Chapter 5 is an explanation of the control circuitry associated with the microcontroller to
reset. Also shows the clocks on the board
– Chapter 6 covers the connector pinout, peripherals and jumper description
– Chapter 7 shows the memory map
– Chapter 8 provides the schematics
– Chapter 9 contains the revision history
Page 6 of 32
STM32-P207 user's manual
