CHAPTER 1 OVERVIEW

1. Introduction to the chapter

Thank you for choosing the STM32-P207 development board from Olimex! This document
provides a user's guide for the Olimex STM32-P207 development board. As an overview, this
chapter gives the scope of this document and lists the board's features. The document's
organization is then detailed.
The STM32-P207 development board enables code development of applications running on the M3
CORTEX STM32F207ZET6 microcontroller, manufactured by STMicroelectronics.

1.1 Features

CPU: STM32F207ZET6 120Mhz 32 bit ARM-based microcontroller with 512 KB Flash,
•
128 (112+16) KB RAM, USB OTG HS and USB OTG HS, Ethernet, 14 timers, 3 SPI, 3
I2C, Ethernet, 2 CANs, 3 12 bit ADCs, 2 12 bit DACs, 114 GPIOs, Camera interface
TAG connector with ARM 2x10 pin layout for programming/debugging
•
512 KB fast external SRAM on board
•
4 Status LEDs
•
Stereo Audio Codec CS4344
•
CAN driver
•
Temperature sensor
•
Trimmer potentiometer
•
Joystick for navigation
•
6610 LCD color 128x128 pixel TFT display
•
SAMSUNG E700 VGA camera 640x480 color
•
Tamper and Wakeup buttons
•
2 RS232 drivers and connectors
•
25 Mhz quartz crystal
•
USB_OTG
•
USB_HOST
•
100 Mbit Ethernet
•
Mini SD/MMC card connector
•
UEXT connector
•
Power Jack
•
RESET button and circuit
•
