OLIMEX© 2012
6.5 USB HOST
PIN#
SIGNAL NAME
1
+5 V
2
USB_HOST_D-
3
USB_HOST_D+
4
GND
6.6 LAN connector
PIN#
1
2
3
4
5
6
7
8
LED
Right
Left
6.7 PWR Jack
Pin #
Signal Name
1
Power Input
2
GND
SIGNAL
NAME
TX+
TX-
VDD
NOT CONNECTED
NOT CONNECTED
VDD
RX+
RX-
Color
Green
Yellow
Link status
Activity status
Page 18 of 32
STM32-P207 user's manual
