OLIMEX© 2012
STM32-P207 user's manual
CHAPTER 8 SCHEMATICS
8. Introduction to the chapter
In this chapter are located the schematics describing logically and physically STM32-P207.
8.1 Eagle schematic
STM32-P207 schematic is visible for reference here. You can also find them on the web page for
STM32-P207 at our site:
https://www.olimex.com/Products/ARM/ST/STM32-
P207/resources/STM32-P207-P407_rev_D.pdf. They are located in HARDWARE section.
The EAGLE schematic is situated on the next page for quicker reference.
Page 27 of 32
