STM32-P207 user's manual
Default state is closed.
R-T
RST and TRST are separated if open.
RST and TRST are connected if closed.
Refer to the schematic near the JTAG connector for how this jumper influences the JTAG
programming of the board.
Default state is open .
CAN_T
Can termination is disabled if open.
Default state is open .
6.15 LCD Display with backlight
replica of Nokia 6610 color display 128x128 pixels
6.16 VGA Color Camera
640x480 pixels (0.3 mega pixel) Samsung 700 camera + connector
6.17 Additional hardware components
The components below are mounted on STM32-P207 but are not discussed above. They are listed
here for completeness:
Joystick
Temperature sensor
Audio out
Trimmer
Buzzer
Additional memory
Page 23 of 32
