Server blade components

1 CPU0
2 CPU0 power connector
3 Mezzanine connector 1 (type
1)
4 Mezzanine connector 2 (type
1 or 2)
5 System board thumbscrew
6 System board thumbscrew
7 Battery (CR2032)
8 ICH mezzanine connector
9 Mezzanine connector 3
(type 1 or 2)
10 CPU1 power connector
11 CPU1
12 SAS backplane
13 Pull tab
NOTE:
The iLO 3 password is
located on the pull
tab.
