Online/activity LED (green)
Flashing irregularly
Flashing irregularly
Off
Off
Off
Table 13: SAS disk drive LEDs : HBA mode
Drive activity LED status Drive status LED
Off, or flashing
Off, or flashing
Flashing irregularly
Flashing irregularly
Off
Off
Off
Off
Fault/UID LED (amber/blue)
Amber, flashing regularly (1 Hz)
Off
Steadily amber
Amber, flashing regularly (1 Hz)
Off
Indication
status
Alternating amber The drive has failed, or a predictive failure alert has
and blue been received for this drive; it also has been
selected by a management application.
Blue The drive is operating normally, and it has been
selected by a management application.
Regularly flashing The drive is active, but a predictive failure alert has
amber(1 Hz) been received for this drive. Replace the drive as
soon as possible.
Off The drive is active, and it is operating normally.
Amber A critical fault condition has been identified for this
drive. Replace the drive as soon as possible.
Regularly flashing A predictive failure alert has been received for this
amber(1 Hz) drive. Replace the drive as soon as possible.
Off The drive is online.
Off Normal operation; no activity
Interpretation
The drive is active, but a
predictive failure alert has been
received for this drive. Replace
the drive as soon as possible.
The drive is active, and it is
operating normally.
A critical fault condition has been
identified for this drive, and the
controller has placed it offline.
Replace the drive as soon as
possible.
A predictive failure alert has been
received for this drive. Replace
the drive as soon as possible.
The drive is offline, a spare, or
not configured as part of an
array.
Troubleshooting 97
