Site preparation

The BL860c i4 does not have cooling or power systems. Cooling and power is provided by the c-Class
enclosure.
IMPORTANT:
To avoid hardware damage, allow the thermal mass of the product to equalize to the temperature
and humidity of the installation facility after removing the shipping materials. A minimum of one hour
per 10°C (50°F) of temperature difference between the shipping facility and installation facility is
required.

Server blade dimensions and weight

Table 1: Server blade dimensions and weight for the BL860c i4
Dimensions
Height
Width
Depth
Weight
Table 2: Blade Link dimensions and weight
Blade Link type
BL1 (BL860 i4)
BL2 (BL870 i4)
BL4 (BL890 i4)

Enclosure information

All three blade configurations are supported in HPE c7000 and c3000 Enclosures.
For more enclosure information see:
• http://www.hpe.com/support/Bladesystem_c3000_Enclosures_Manuals
• http://www.hpe.com/support/Bladesystem_c7000_Enclosures_Manuals
10 Site preparation
value
36.63 cm (14.42 in.)
5.14 cm (2.025 in.)
48.51 cm (19.1 in.)
Unloaded: 8.6 kg (19 lb)
Fully loaded: 11.3 kg (25 lb)
Height
44 mm (1.73 in)
44 mm (1.73 in)
44 mm (1.73 in)
Width
51 mm (2 in)
106 mm (4.17 in)
212 mm (8.34 in)
Weight
.5 lb (.22 kg)
1 lb (.45 kg)
2 lb (.90 kg)
