Mechanical Installation

3 Mechanical Installation

3.1 Identification and Variants

3 3
Confirm that the equipment matches the requirements and
ordering information by checking power size, voltage data,
and overload data on the nameplate of the frequency
converter.
VLT
1
T/C: FC-360HK37T4E20H2BXCDXXSXXXXAXBX
2
P/N: 134F2970
0.37 kW 0.5HP High Overload
IN: 3x380-480V 50/60Hz 1.24/0.99A
3
OUT: 3x0-Vin 0-500Hz 1.2/1.1A(Tamb. 45 C)
CHASSIS/IP20
1 Type code
2 Ordering number
3 Specifications
Illustration 3.1 Nameplates 1 and 2
1 2 3
F C -
Illustration 3.2 Type Code String
10
VLT
Automation Drive
www.danfoss.com
S/N: 691950A240
Danfoss A/S
6430 Nordborg
Denmark
o
MADE BY DANFOSS IN CHINA
CAUTION:
SEE MANUAL
WARNING:
STORED CHARGE DO NOT TOUCH UNTIL 4 MIN. AFTER
DISCONNECTION
RISK OF ELECTRIC SHOCK-DUAL SUPPLY DISCONNECT MAINS
AND LAODSHARING BEFORE SERVICE
4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
3 6 0 H T 4
Q
Danfoss A/S © 03/2017 All rights reserved.
®
AutomationDrive FC 360
1–6: Product Name
7: Overload
8–10: Power size
11–12: Voltage class
13–15: IP class
16–17: RFI
18: Brake chopper
19: LCP
20: PCB coating
21: Mains terminals
29–30: Embedded
fieldbus
31–32: Option B
Table 3.1 Type Code: Selection of Different Features and Options
For options and accessories, refer to the section Options and
Accessories in the VLT
1) Only 11–75 kW (15–100 hp) for normal duty variants. PROFIBUS
and PROFINET are unavailable for normal duty.
2) For all power sizes, see chapter 8.1.1 Mains Supply 3x380–480 V
AC.
3) 0.37–22 kW (0.5–30 hp) with built-in brake chopper. 30–75 kW
(40–100 hp) with external brake chopper only.
E 2 0 H 2 X X C D
B
H: Heavy duty
Q: Normal duty 1)
0.37–75 kW (0.5–100 hp). For example:
K37: 0.37 kW 2) (0.5 hp)
1K1: 1.1 kW (1.5 hp)
11 K: 11 kW (15 hp)
T4: 380–480 V 3-phases
E20: IP20
H2: C3 Class
X: No
B: Built-in 3)
X: No
C: 3C3
D: Load sharing
AX: No
A0: PROFIBUS
AL: PROFINET
BX: No option
BR: MCB-102 Encoder
BU: MCB-103 Resolver
®
AutomationDrive FC 360 Design Guide.
