Wiring Schematic - Danfoss VLT AutomationDrive FC 360 Quick Manual

Electrical Installation

4.4 Wiring Schematic

This section describes how to wire the frequency converter.
RFI
91 (L1)
3 phase
92 (L2)
power
93 (L3)
input
95
50 (+10 V OUT)
+10 V DC
0-10 V DC
53 (A IN)
0/4-20 mA
0-10 V DC
54 (A IN)
0/4-20 mA
55 (COM A IN)
12 (+24 V OUT)
18 (D IN)
19 (D IN)
20 (COM D IN)
27 (D IN/OUT)
29 (D IN/OUT)
32 (D IN)
33 (D IN)
31 (D IN)
Illustration 4.2 Basic Wiring Schematic Drawing
A=Analog, D=Digital
1) Built-in brake chopper available from J1–J5.
2) Relay 2 is 2-pole for J1–J3 and 3-pole for J4–J7. Relay 2 of J4–J7 with terminals 4, 5, and 6 has same NO/NC logic as relay 1.
Relays are pluggable in J1–J5, and fixed in J6–J7.
3) Single DC choke in J1–J5; Dual DC choke in J6–J7.
4) Switch S801 (bus terminal) can be used to enable termination on the RS485 port (terminals 68 and 69).
5) No BR for J6–J7.
MG06A702
Quick Guide
3)
PE
Switch Mode
Power Supply
10 V DC
15 mA
+ -
P 5-00
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V
0 V
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
