Danfoss VLT AutomationDrive FC 360 Quick Manual page 29

Commissioning
Array parameters function as follows:
Setup 1
5 x
1
OK
Setup 1
INDEX
2
OK
Setup 1
INDEX
Setup 1
INDEX
OK 4
Setup 1
INDEX
Illustration 5.9 Main Menu Interactions - Array Parameters
1 [OK]: Shows parameter numbers and the value in the first
index.
2 [OK]: Index can be selected.
▲ ▼
3
[ ][ ]: Select index.
4 [OK]: Value can be edited.
▲ ▼
5
[ ][ ]: Change parameter value (flashing).
6 [Back]: Cancels changes.
[OK]: Accepts changes.
7 [Back]: Cancels editing index, a new parameter can be
selected.
▲ ▼
8
[ ][ ]: Select parameter within the group.
9 [Back]: Removes parameter index value and shows the
parameter group.
▲ ▼
10
[ ][ ]: Select group.
Table 5.7 Changing Values in Array Parameters
5.4.6 Graphical Local Control Panel
The graphical local control panel LCP 102 has a larger
display area, which shows more information than LCP 21.
LCP 102 supports English, Chinese, and Portuguese
displays.
The GLCP is divided into 4 functional groups (see
Illustration 5.10).
A. Display area.
B. Display menu keys.
MG06A702
Quick Guide
10
9
8
%
% 7
OK
%
6
10
%
5
15
16
17
Illustration 5.10 Graphic Local Control Panel (GLCP)
A. Display area
The display area is activated when the frequency converter
receives power from the mains voltage or a DC bus
terminal.
The information shown on the LCP can be customized for
user applications. Select options in the Quick Menu Q3-13
Display Settings.
Table 5.8 Legend to Illustration 5.10, Display Area
B. Display menu keys
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
6
Danfoss A/S © 03/2017 All rights reserved.
C. Navigation keys and indicator lights (LEDs).
D. Operation keys and reset.
1
Status
7.83 A
799 RPM
0.000
2
A
53.2 %
4
Auto Remote Ramping
6
Quick Main
Status
B
Menu Menu
7
C
On
OK
Warn.
Alarm
Hand Auto
D
O
On
18 19
Display Parameter number
1 0-20
2 0-21
3 0-22
4 0-23
5 0-24
Key
Status Shows operational information.
3
1(1)
36.4 kW
5
9
Alarm
Log
8
11
12
13
Reset
On
14
20 21
Default setting
[1602] Reference [%]
[1614] Motor Current
[1610] Power [kW]
[1613] Frequency
[1502] kWh Counter
Function
27
5 5
