Electrical Installation
•
Keep the ground wire connections as short as
possible.
•
Use high-strand wire to reduce electrical noise.
•
Follow motor manufacturer wiring requirements.
4
4
PE
PE
Illustration 4.1 Grounding Principle
14
VLT
FC 1
FC 2
FC 3
FC 1
FC 2
FC 3
