Danfoss VLT AutomationDrive FC 360 Quick Manual page 30

Commissioning
Key
Quick
7
Menu
8 Main Menu
9 Alarm Log
Table 5.9 Legend to Illustration 5.10, Display Menu Keys
C. Navigation keys and indicator lights (LEDs)
5 5
Navigation keys are used for programming functions and
moving the display cursor. The navigation keys also
provide speed control in local operation. There are also 3
frequency converter status indicator lights in this area.
Key
10 Back
11 Cancel
12 Info
Navigation
13
keys
14 OK
Table 5.10 Legend to Illustration 5.10, Navigation Keys
Indicator
15 On
16 Warn
17 Alarm
Table 5.11 Legend to Illustration 5.10, Indicator Lights (LEDs)
28
VLT
Function
Allows access to programming parameters
for initial set-up instructions and many
detailed application instructions.
Allows access to all programming
parameters.
Shows a list of current warnings, the last 10
alarms, and the maintenance log.
Function
Reverts to the previous step or list in the
menu structure.
Cancels the last change or command as long
as the display mode has not changed.
Press for a definition of the function being
shown.
To move between items in the menu, use the
4 navigation keys.
Press to access parameter groups or to
enable a selection.
Light Function
ON turns on when the frequency
converter receives power from the
Green
mains voltage or a DC bus
terminal.
When warning conditions are met,
the yellow WARN LED turns on,
Yellow
and text appears in the display
area identifying the problem.
A fault condition causes the red
Red alarm LED to flash, and an alarm
text is shown.
Danfoss A/S © 03/2017 All rights reserved.
®
AutomationDrive FC 360
D. Operation keys and reset
Operation keys are at the bottom of the LCP.
Key
18 Hand On
19 Off
20 Auto On
21 Reset
Table 5.12 Legend to Illustration 5.10, Operation Keys and Reset
NOTICE
To adjust the display contrast, press [Status] and the
▲ ▼
[ ]/[ ] keys.
5.4.7 Changing Parameter Settings with
GLCP
Access and change parameter settings from the Quick
Menu or from the Main Menu. The Quick Menu only gives
access to a limited number of parameters.
1. Press [Quick Menu] or [Main Menu] on the LCP.
2.
Press [
groups, press [OK] to select a parameter group.
3.
Press [
press [OK] to select a parameter.
4.
Press [
setting.
5. Press [◄] [►] to shift digit when a decimal
parameter is in the editing state.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter Status, or press
[Main Menu] once to enter the Main Menu.
View changes
Quick Menu Q5 - Changes Made lists all parameters
changed from default settings.
•
The list only shows parameters, which have been
changed in the current edit set-up.
•
Parameters which have been reset to default
values are not listed.
•
The message Empty indicates that no parameters
have been changed.
Function
Starts the frequency converter in hand-on
mode.
•
An external stop signal by control input
or serial communication overrides the
local hand on.
Stops the motor but does not remove power
to the frequency converter.
Puts the system in remote operational mode.
•
Responds to an external start command
by control terminals or serial communi-
cation.
Resets the frequency converter manually
after a fault has been cleared.
▲ ▼
] [ ] to browse through the parameter
▲ ▼
] [ ] to browse through the parameters,
▲ ▼
] [ ] to change the value of a parameter
MG06A702
