No. Parameter name
Motor direction
P11
Electronic gear
P12
numerator
1－pulse＋pulse
2－quadrate pulse
3－pulse＋direction (500K)
Read only, it can only be set by dial switch SW1/SW2.
SW1
00=P+D
01=CCW+CW
10=A+B
11= P+D
0 － forward;
1 － reverse;
Set sub-frequency multiplication of position command
pulse (electronic gear);
In electronic gear ratio control mode, set parameter P12
and P13 to easily achieve pulse equivalent matching;
considering that the acceptable frequency range of the
drive is lower than 500K, increase the value as much as
possible;
P× G=N× C× 4
P:pulse number of input instruction;
G:electronic gear ratio;
Frequency division numerator
G
Frequency division denominator
N:motor rotation number;
C:wire number of photoelectrical encoder: generally
2500;
QS2 Series Low Voltage Servo Drive
Function
SW2
100khz
100khz
100khz
500Khz
44
Range
0－1
1－32000
