Adtech QS2 Series Manual page 43

No. Parameter name
Servo enable
P5
control
Function of
servo input
P6
signal INTH
Limit input
P7
control
COIN output
P8
mode
Alarm output
P9
mode
Pulse mode
P10
7－4 gear speed control
8－4 gear position control
9－communication control
0－valid;
1－invalid compulsory axis locking
Not support reservation function for now
0－invalid;
1－valid in low level with no alarm;
2－valid in high level with no alarm;
3－valid in low level with alarm;
4－valid in high level with alarm;
0－positioning completion;
1－torque arrival;
2－output when speed less than P49 (if 如 P49 is
less than 10RPM, deemed as 10RPM) ;
0－normally closed type;
1－normally open type;
0－pulse＋direction (100K)
43
QS2 Series Low Voltage Servo Drive
Function Range
0－1
0－1
0－4
0－2
0－1
0－3
