Adtech QS2 Series Manual page 10

Instruction
percentage
Instruction source External analog quantity, internal speed instruction
Analog instruction
input
Torque Instruction
mode acceleration and
deceleration
Instruction
percentage
Instruction source External analog quantity, internal torque instruction
Pulse output
Input/outpu
signal
t signal
Input signal
Output signal
Protection
function
Monitoring
functions
Built-in
functions
Communication
functions
Indication
functions
Speed regulating
Other
features
fluctuation rate
Parameter setting
-10V~10V, input impedance 10kΩ
Parameter setting
Parameter setting
Differential output of A, B and Z phases of encoder
Servo enable, alarm clearance, forward limit, reverse limit,
control method
Position completion, servo alarm
Over current, overvoltage, under voltage, overload, encoder
exception and other alarms
Rotation speed, current position, current pulse frequency,
position deviation, motor current, analog input value, etc.
Achieve communication with PC via RS232 or RS485, and
achieve parameter modification and servo system running
status monitoring (RS232 and RS485 can't be used
simultaneously. You can use DIP switch to select the
desired communication. For details see the Chapter 4.)
Red (alarm), green (working) indicator
1:5000
ratio
Speed
<± 0.03% (within rated load)
QS2 Series Low-voltage Servo Drive
10
