3.2.2. Details on Interface

(1)Power terminal
No.
1
2
3
(2)Terminal of motor power cable
No.
1
2
3
4
(3)Terminal of CN1 controller signal wire: the board terminal CN1 is the socket
component for DB26 on the receptacle.
QS2 series low voltage servo drive controller signal wire terminals are as
follows:
Code
Power grounding
GND
Main power input 24~80VDC
VDC
Connecting pin for brake resistance (the brake
BR
resistance is connected between VDC and BR)
Code
Black
W
Green
V
Red
U
Yellow
PE
9
18
26
Note: From the side of bonding wire
QS2 Series Low Voltage Servo Drive
Signal function
Color
Connected with motor housing
1
10
19
18
Signal function
Motor UVW
