Getting Started

Getting started with the MOPSlcdLX is very easy. Take the following steps:
‚
Plug a suitable DDR-SDRAM memory module into the RAM socket.
ƒ
Plug the MOPSlcdLX to the PC/104 bus connector on the starter kit baseboard.
„
Make all necessary connections from the MOPSlcdLX to the starter kit board (cables come with
the starter kit). The starter kit board offers various interfaces on standard connectors.
…
Connect the CRT monitor to the CRT interface or a LCD panel to the JILI interface by using the
corresponding adapter cable.
†
Plug a keyboard and/or mouse to the PS/2 connectors.
‡
Plug a data cable to the hard disk interface. Attach the hard disk to the connector at the oppo-
site end of the cable. If necessary connect the power supply to the hard disk's power connec-
tor.
ˆ
Make sure all your connections have been made correctly. Turn on the power.
‰
Enter the BIOS by pressing the Del key during boot-up. Make all changes in the BIOS Setup.
See the BIOS Setup chapter of this manual for details.
