B.3

Mating Connectors

The table notes mating connectors.
Identifier
X12001
X14001
X15000
X15001
X15002
X15004
X15005
X15006
X15007
X16000
Page 44
Mating Connector
1.25 mm 6 pin
(MOLEX 51021-0600 or comp.)
1.25 mm 4 pin
(MOLEX 51021-0400 or comp.)
2.54 mm 10 pin
(AMP 1-215882-0 or comp.)
2.54 mm 10 pin
(AMP 1-215882-0 or comp.)
2.54 mm 26 pin
(AMP 2-215882-6 or comp.)
2 mm 44 pin
(Berg 89361-144 or comp.)
1.25 mm 4 pin
(MOLEX 51021-0400 or comp.)
2 mm 8 pin
(Berg 90311-008 or comp.)
MOPSlcdLX User's Guide
Appendix B: Connector Layout
Comment
for DSUB15 adaptation (CRT)
for PS/2 mouse
for DSUB9 adaption (COMA, COMB)
for keyboard/feature connector
for DSUB25 adaption (LPT)
for IDE connector
for USB connectors
for RJ45 adaption
