Mechanical Specifications

Dimensions
96 x 90 mm (3.77" x 3.55")
®
Height on top approx. 11.5 mm
®
Height on bottom approx. 10.5 mm
®
3.4

Electrical Specifications

Supply Voltage
+5V DC ± 5%
®
Supply Voltage Ripple
Maximum 100mV peak to peak 0 – 20 MHz
®
Supply Current (DOS prompt)
Power consumption tests were executed during the DOS prompt with 256 MB DDR SDRAM, CRT monitor, USB
keyboard and CF card as boot device (default BIOS settings).
Supply Current (Windows
The power consumption tests were executed during Windows
(100% load) and extensive 2D graphic. The boards were ran with 256 MB DDR SDRAM, CRT monitor, PS/2
keyboard, USB mouse and a CF card as boot device (default BIOS settings).
Page 7
Full Load
[A] [W]
1.10 5.50
®
XP SP3)
Full Load
[A] [W]
1.45 7.25
MOPSlcdLX User's Guide
Soft Off S5
[A] [W]
0.20 1.00
®
XP SP3 by using a tool to stress the CPU
Idle
[A] [W]
0.95 4.75
