EVALUATION BOARD SETUP PROCEDURES

The AD7276 evaluation board connects to the
CB1Z system demonstration board. The
board is the controller board, which is the communication link
between the PC and the main evaluation board. Figure 2 shows
a photograph of the connections made between the
daughter board and the EVAL-SDP-CB1Z
After following the instructions in the Software Installation
Procedures section, set up the evaluation and SDP boards as
detailed in this section.
Warning
The evaluation software and drivers must be installed before con-
necting the evaluation board and
the USB port of the PC to ensure that the evaluation system is
correctly recognized when it is connected to the PC.
EVAL-SDP-
EVAL-SDP-CB1Z
AD7276
board.
EVAL-SDP-CB1Z board to
Rev. 0 | Page 7 of 20
Configuring the Evaluation and SDP Boards
1. Connect the EVAL-AD7276SDZ
Connector B of the EVAL-SDP-CB1Z
a. Screw the two boards together using the nylon screw-
nut set included in the evaluation board kit to ensure
that the boards are connected firmly together.
2. Connect the 9 V power supply adapter included in the evalu-
ation board kit to Connector J1 of the
board. (Alternatively, a bench power supply can be used to
power the EVAL-AD7276SDZ
for more information about the connections and options
for the required power supplies.)
3. Connect the EVAL-SDP-CB1Z
supplied USB cable.
UG-450
board to Connector A or
board (see Figure 2).
EVAL-AD7276SDZ
via Connector J2. See Table 1
board to the PC using the
