EVAL-AD7276SDZ User Guide

GETTING STARTED

QUICK START STEPS

To begin using the evaluation board, do the following:
1. With the EVAL-SDP-CB1Z
USB port of the PC, install the
software from the CD included in the evaluation board kit.
The PC must be restarted after the software installation is
complete. (For complete software installation instructions,
see the Software Installation Procedures section.)
2. Connect the EVAL-SDP-CB1Z
AD7276SDZ board as shown in Figure 2. Screw the two
boards together using the nylon screw-nut set included in
board disconnected from the
AD7276 evaluation board
board to the EVAL-
9V PSU
Figure 2. Hardware Configuration—Setting up the
(EVAL-AD7276SDZ
Rev. 0 | Page 3 of 20
the evaluation board kit to ensure that the boards are
connected firmly together.
3. Connect the 9 V power supply adapter included in the
evaluation board kit to Connector J1 on the
AD7276SDZ
4. Connect the
supplied USB cable. If you are using Windows® XP, you may
need to search for the
automatically search for the drivers for the
board if prompted by the operating system.
5. Launch the
Devices subfolder in the Programs menu.
EVAL-AD7276SDZ
on Left and EVAL-SDP-CB1Z on Right)
board.
EVAL-SDP-CB1Z board to the PC using the
EVAL-SDP-CB1Z
EVAL-AD7276SDZ software from the Analog
EVAL-SDP-CB1Z
USB TO PC
UG-450
EVAL-
drivers. Choose to
EVAL-SDP-CB1Z
