UG-450

MODES OF OPERATION

SDP CONTROLLED MODE

The AD7276 uses a high speed serial interface that allows
sampling rates of up to 3 MSPS. For more information about
the operation of the serial bus, refer to the
The EVAL-AD7276SDZ communicates with the
board using level shifters. The
3.3 V logic level, which allows logic voltages that exceed 3.3 V
to be used without damaging the SDP interface.

STANDALONE MODE

The EVAL-AD7276SDZ can also be used without the
CB1Z controller board. In this case, the
AD7276 data sheet.
EVAL-SDP-CB1Z
EVAL-SDP-CB1Z operates at a
EVAL-SDP-
EVAL-AD7276SDZ
connected to the digital interface using the SMB connectors as
described in Table 7.
Table 7. Standalone Jumper Settings
Pin SMB
CS J6
SCLK J8
SDATA J9
is
Rev. 0 | Page 12 of 20
EVAL-AD7276SDZ User Guide
Jumper Setting
Shorting link in Position B
Shorting link in Position B
Shorting link in Position B
