UG-815
GETTING STARTED
INSTALLING THE SOFTWARE
The
EVAL-AD5675SDZ
and
boards use the Analog Devices ACE software. ACE is a desktop
software application that allows the evaluation and control of
multiple evaluation systems.
The ACE installer installs necessary SDP drivers and .NET
Framework 4 by default. Install ACE before connecting the SDP
board to the USB port of the PC to ensure that the SDP board is
recognized when it connects to the PC. Use the following link
to download the software, and access full instructions on how
to install and use this software: http://www.analog.com/ace.
After the installation is finished the
EVAL-AD5675RSDZ
evaluation board plug-ins appear when
you open ACE.
INITIAL SETUP
To set up the evaluation board, take the following steps:
1.
Connect the evaluation board to the
connect the USB cable between the
2.
Power the
SDP-B
and evaluation board by connecting
6 V dc to the J3 connector.
3.
Run the ACE application. The EVAL-AD5675SDZ/
EVAL-AD5675RSDZ
board plug-ins appear in the
attached hardware section of the Start tab.
4.
Double-click on the board plug-in to open the board view
seen in Figure 2.
5.
The chip block diagram can be accessed by double-clicking
on the
AD5675
or
AD5675R
basic representation of functionality of the board. The
main functions are labeled in Figure 3.
EVAL-AD5675RSDZ
evaluation
EVAL-AD5675SDZ
and
SDP-B
board and
SDP-B
board and the PC.
chip. This view provides a
Figure 2. Board View of the
Figure 3. Chip Block Diagram view for the
Rev. A | Page 4 of 13
Evaluation Board User Guide
EVAL-AD5675RSDZ
