EVAL-AD7276SDZ User Guide
EVALUATION BOARD CIRCUITRY
ANALOG INPUTS
Two analog input options are available for the EVAL-AD7276SDZ:
•
VIN (J7)—for use with a unipolar signal source
•
VIN UNBIASED (J5)—for use with a bipolar signal source
VIN (J7)
Use the VIN (J7) input when a unipolar signal source is avail-
able (see Table 4 for jumper settings). The input is buffered by
U7 and fed to the
AD7276
via an R-C filter.
Table 4. Unipolar Input Jumper Settings
Link
Jumper Settings
LK8
Removed
All Other Links
Set as described in Table 3.
VIN UNBIASED (J5)
Use the VIN UNBIASED (J5) input when a bipolar signal source is
available (see Table 5 for jumper settings). The input is biased up
by U6 and buffered by U7 and then is fed to the
R-C filter.
Table 5. Bipolar Input Jumper Settings
Link
Jumper Settings
LK11
Removed
All Other Links
Set as described in Table 3.
REFERENCE OPTIONS
The following on-board reference supply is available:
•
AD780: 2.5 V/3.0 V ultrahigh precision band gap voltage ref-
erence. The reference is taken from the V
Alternatively, an external reference voltage can be applied to J4.
AD7276
via an
pin of the AD7276.
DD
Rev. 0 | Page 11 of 20
SOCKETS/CONNECTORS
Table 6. Socket/Connector Functions
Socket
Function
J1
PWR. A 7 V to 9 V dc transformer power connector.
J2
A 7 V to 9 V bench supply screw terminal connector.
J3
V
and V
. Screw terminal connectors for external
SS
DD
amplifier power supplies.
J4
External power supply for V
J5
VIN UNBIASED. Analog input for use with bipolar
signal sources.
J6
CS. External connection to CS .
J7
VIN. Analog input for use with unipolar signal sources.
J8
SCLK. External connection to SCLK.
J9
SDATA. External connection to SDATA.
J10
EVAL-SDP-CB1Z
UG-450
of the AD7276.
DD
evaluation board controller socket.
