EVAL-AD7761FMCZ User Guide

SOCKETS/CONNECTORS

Table 4. Connector Details
Connector Function
J1 Wall wart (dc plug) power supply voltage
input. Apply 7 V.
J2 Apply voltage within data sheet specified
ranges and GND (0 V) to this connector to
power the evaluation board. J2 is the
connector for supplying AVDD1, AVDD2,
IOVDD, AVSS, and AGND externally.
J3 Bench top power supply voltage input. Apply
7 V to 9 V and GND (0 V) to this connector to
power the evaluation board.
J6 SMA/SMB connector for XTAL2 (CLKIN/LVDS).
J7 SMA/SMB connector for XTAL1 (LVDS).
J8, J9 8-pin connector for input to Channel 4 to
Channel 7.
J11 Optional external connector for driver
daughter board to Channel 5.
J12 Optional external connector for driver
daughter board to Channel 5.
J13, J14 8-pin connector for input to Channel 0 to
Channel 3.
J15 Unpopulated VCM SMA connector.
AI0+ to Analog input SMA positive terminals for
AI7+ Channel 0 to Channel 7.
AI0− to Analog input SMA negative terminals for
AI7− Channel 0 to Channel 7.
P1 Connection to
board.

EVALUATION BOARD SETUP PROCEDURES

After following the instructions in the Software Installation
Procedures section, set up the evaluation and SDP boards as
detailed in this section.
Warning
The evaluation software and drivers must be installed before
connecting the evaluation board and
to the USB port of the PC to ensure that the evaluation system
is correctly recognized when it is connected to the PC.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
EVAL-SDP-CH1Z controller
EVAL-SDP-CH1Z board
Connector Type Manufacturer/Part No.
2 mm dc power Kycon KLDX-SMT2-0202-A
connector
5-pin socket terminal Lumberg FRE 05
block
3-pin socket terminal Phoenix Contact MC
block, 3.81 mm pitch 1,5/3-G-3,81
Straight PCB mount Tyco 1-1337482-0
SMB/SMA jack
Straight PCB mount Tyco 1-1337482-0
SMB/SMA jack
8-pin socket terminal Phoenix Contact MC
block, 3.81 mm pitch 1,5/8-G-3,81
7-way, 2.54 mm vertical Samtec SSW-107-01-T-S
socket
7-way, 2.54 mm TH Samtec TLW-107-05-G-S
header
8-pin socket terminal Phoenix Contact MC
block, 3.81 mm pitch 1,5/8-G-3,81
Straight PCB mount Tyco 1-1337482-0
SMB/SMA jack
Straight PCB mounts Tyco 1-1337482-0
SMB/SMA jack
Straight PCB mounts Tyco 1-1337482-0
SMB/SMA jack
160-pin, 10 mm male Samtec ASP-134604-01
VITA 57 connector
Configuring the Evaluation and SDP Boards
Connect the EVAL-SDP-CH1Z
EVAL-AD7761FMCZ
Rev. 0 | Page 9 of 17
UG-949
Order No.
Mouser 806-KLDX-
SMT20202A
Farnell 1217310
Farnell 3704737
Not inserted
Not inserted
Farnell 3704774
Farnell 1803478
Farnell 1668499
Farnell 3704774
Farnell 3704737
Farnell 1206013
Farnell 1206013
Farnell 2433507
board to P1 (bottom) on the
board.
