EVAL-AD5693RSDZ User Guide

EVALUATION BOARD QUICK START PROCEDURES

INSTALLING THE SOFTWARE

The EVAL-AD5693RSDZ evaluation board uses the
software, a desktop software application that allows the
evaluation and control of multiple evaluation systems.
The ACE installer installs necessary SDP drivers and the
Microsoft® .NET Framework 4 by default. The
available for download from the
page and must be installed before connecting the SDP board to the
USB port of the PC, to ensure that the SDP board is recognized
when it connects to the PC. For full instructions on how to install
and use this software, see the
Devices website.
After the installation is finished, the
evaluation board plug in appears when the
opened.
ACE
ACE software is
EVAL-AD5693RSDZ product
ACE software page on the Analog
EVAL-AD5693RSDZ
ACE software is
Figure 2. Board View of the

INITIAL SETUP

To set up the evaluation board, take the following steps:
1. Connect the evaluation board to the SDP board, and then
connect a USB cable between the SDP board and the PC.
2. Run the ACE
plug ins appear in the attached hardware section of the
Start tab.
3. Double click the board plug in to open the board view,
shown in Figure 2.
4. Double click the AD5693R chip to access the chip block
diagram. This view provides a basic representation of
functionality of the board. The main function blocks of the
board are labeled in Figure 3.
EVAL-AD5693RSDZ
Rev. A | Page 3 of 12
application. The EVAL-AD5693RSDZ
UG-675
board
