Installing the Storage Shelf guide rails

1
Peel the protective film from the top of the storage shelf.
2
Lift up one end of the storage shelf and peel the film from the bottom of the
chassis.
3
When approximately half of the film is removed, lift the other end of the storage
shelf and remove the remaining film.
4
Peel the film from the sides of the storage shelf.
5
Discard all of the film.
See "Installing the Storage Shelf guide rails" on page 31.
The Storage Shelf is shipped with left and right mounting rails. These rails install
in a standard 19-inch rack. The front plates of the rails are marked left and right.
Two-inch lips on the bottoms of the rails provide a shelf on which the storage system
sits. Extenders that are built into the rails let you adjust the rails for the depth of the
rack.
Caution: Due to the weight of the units, Veritas recommends that storage shelves
be installed at or near the bottom of the rack.
Requirements
19-inch equipment rack
■
Available 3U slot
■
Six M5 screws (provided)
■
Six cage nuts (provided)
■
Number 2 Phillips screwdriver
■
Flashlight
■
Installing hardware into racks
Installing the Storage Shelf guide rails
