30 Installing hardware into racks

Removing the protective film from the storage shelf

Removing the protective film from the storage
shelf
Height: 13.1 cm (5.25")
■
Width: 44.7 cm (17.6")
■
Depth: 56.1 cm (22.1")
■
Weight: 32.5 kg (71.7 lbs)
■
The rack rails that are provided for the Storage Shelf are extensible to 36" (914mm).
This distance is the maximum depth that is allowed between rack posts. If the
distance between rack posts is longer than 36" (914mm) the rails and the appliance
cannot be properly installed. The width of the storage shelf is 19" (482.6mm).
Appliance weight and dimensions:
52 pounds (23.58 kg)
■
27.39" (69.59 cm) deep
■
17.24" (43.8 cm) wide
■
3.45" (8.76 cm) high
■
The rack rails that are provided for the appliance are extensible to 30" (752mm).
This distance is the maximum depth that is allowed between rack posts. If the
distance between rack posts is longer than 30" (752mm) the rails and the appliance
cannot be properly installed. The width of the appliance is 19" (482.6mm).
Make sure that the installation location has extra space for the following:
Front bezels and rack handles
■
Rear panel power supply latches
■
Rear panel cable connectors
■
The Storage Shelf ships with a clear, protective film on the top, bottom, and sides
of the chassis. You need to remove the film before you install the storage shelf into
the rack. The storage shelf does not install properly if the film is not removed.
The front panel and the rear panel do not include any film.
To remove the protective film
Warning: Make sure that another person is available to help lift the storage shelf.
