NetBackup Appliance rear panel (continued)
Table 1-3
Number Function
8 RJ45 Serial-A port (reserved)
9 USB connectors
10 Remote management (IPMI) port
11 NIC5/eth4 and NIC6/eth5, left to right: 10Gb network connectors for public
networks
12 PCIe add-in adapter slots (for SAS RAID Controller, Fibre Channel, and
10Gb Ethernet cards)
13 Serial-B port (reserved)
NetBackup 5230 appliances ship with grounding studs in case your lab environment
has such a requirement. The studs are located on the rear panel of the appliance.
You can use standard grounding practices to connect grounding wires to the studs.
The serial number of the appliance is located on the rear panel of the appliance.
See "Storage shelf front panel" on page 12.
Introduction 11
Appliance rear panel
