Epson S1R75801F00A Technical Manual page 66

S1R72803F00A
Address Register Name
0x32 SBP2IntStat
Hardware SBP2 Interrupt Status Register
This register indicates error information when an error arises in execution of the hardware SBP2 processing.
At the same time, it asserts the HwSBP2Err bit of the SubIntStat Register. When clearing it, write "1" to a bit
to clear.
This register is automatically cleared when setting HwSBP2Ctl.HwSBP2Start or the HWSBP2Ctl. HwSBP2Rst.
Bit7 Split Timeout
• SplitTimeOut:1 => During the HwSBP2 processing, an SPLIT TIMEOUT error arose.
Bit6 Tx Acked Illegal
TxAckedIllegal:1 => Though a transmission was completed, a response other than ack_pending was given to
a BlkRdReq and a response other than ack_completed was given to a BlkWrReq.
Bit5 Tx Ack Miss
• TxAsyMiss:1 => Though a transmission was completed, no Ack was returned.
Bit4 BRAbort
• When the HwSBP2Ctl.HwSBP2Start bit is set to "1" or HWSBP2Ctl.Resume bit is set to "1" during the
BusReset period, this bit becomes "1",
Bit3 NotQuad
This bit indicates 1 if SegmentLength of PageTableElement is not the Quad unit during the HwSBP2 process.
No data transmission to the detected PageTableElement occurs.
This bit is cleared when 1 is written.
This bit is automatically cleared when a Transaction starts or SBP2Reset is issued.
Bit2 RxNotRespCmp
• RxNotRespCmp:1 => Though a response packet receive was completed, its code was other than resp_complete.
Bit1 RxBroadcast
• RxBroadCast:1 => Though a response packet receive was completed, it was a broadcast packet.
Bit0 RxAckDataError
• RxAckDataErr:1 => Though a response packet was received, it was a DataCRCError. It does not assert the
interrupt signal SBP2Err. It is automatically cleared on completion of the Transaction.
62
Bit Symbol R/W
7: SplitTimeOut R(W) 0: None
6: TxAckedIllegal R(W) 0: None
5: TxAckMiss R(W) 0: None
4: BrAbort R(W) 0: None
3: NotQuad R(W) 0: None
2: RxNotRespCmp R(W) 0: None
1: RxBroadCast R(W) 0: None
0: RxAckDataErr R(W) 0: None
Description
1: SplitTimeOut
1: TxAckedIllegal
1: TxAsyMiss
1: BrAbort
1: NotQuad
1: RxNotRespCmp
1: RxBroadCast
1: RxAckDataErr
EPSON
H.Rst S.Rst B.Rst
0x00 0x00 –
