3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 26.
5. Install the DIMM on page 47.
6. Install the chassis cover on page 27.
7. Connect all peripheral cables to the server.
8. Connect the power cord to the server power jack, and then to the AC source.
9. Power up the server on page 22.
10. To configure the memory, use the Aptio Setup Utility on page 59. Select Chipset > South Bridge >
Memory Configuration.

Install the DIMM

Procedure
1. Open the DIMM slot latches.
2. Align the notch on the bottom edge of the DIMM with the keyed surface of the DIMM slot, and then fully
press the DIMM into the slot until the latches snap back into place.
The DIMM slots are structured to ensure proper installation. If you try to insert a DIMM but it does not fit
easily into the slot, you might have positioned it incorrectly. Reverse the orientation of the DIMM and insert
it again.
2

Expansion board options

The server has two low-profile, open-ended PCIe3 expansion slots. Use these slots to install additional
hardware capabilities such as:
• An HBA to enable advanced drive features.
• A GPU to accelerate the processing speed of your applications.
• A network adapter with advanced Ethernet connectivity features.

Installing an expansion board

Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 26.
1
2
Install the DIMM 47
