Task
Display ARP entries (distributed devices
in IRF mode).
Display the ARP entry for an IP address
(centralized devices in standalone mode).
Display the ARP entry for an IP address
(distributed devices in standalone
mode/centralized devices in IRF mode).
Display the ARP entry for an IP address
(distributed devices in IRF mode).
Display the ARP entries for a VPN
instance.
Display the aging timer of dynamic ARP
entries.
Clear ARP entries from the ARP table
(centralized devices in standalone mode).
Clear ARP entries from the ARP table
(distributed devices in standalone
mode/centralized devices in IRF mode).
Clear ARP entries from the ARP table
(distributed devices in IRF mode).

Configuration examples

Long static ARP entry configuration example

Network requirements
As shown in
GigabitEthernet 2/0/1 in VLAN 10.
To ensure secure communications between Router A and Router B, configure a long static ARP
entry for Router A on Router B.
Figure 3 Network diagram
Figure 3, hosts are connected to Router B. Router B is connected to Router A through
Command
display arp [ [ all | dynamic | static ] [ chassis chassis-number
slot slot-number ] | vlan vlan-id | interface interface-type
interface-number ] [ count | verbose ]
display arp ip-address [ verbose ]
display arp ip-address [ slot slot-number ] [ verbose ]
display arp ip-address [ chassis chassis-number slot
slot-number ] [ verbose ]
display arp vpn-instance vpn-instance-name [ count ]
display arp timer aging
reset arp { all | dynamic | interface interface-type
interface-number | static }
reset arp { all | dynamic | interface interface-type
interface-number | slot slot-number | static }
reset arp { all | chassis chassis-number slot slot-number |
dynamic | interface interface-type interface-number | static }
7
