Task
standalone mode).
Display NAT statistics (distributed devices in
standalone mode/centralized devices in IRF
mode).
Display NAT statistics (distributed devices in
IRF mode).
Display information about port block group
application for NAT444.
Display information about NAT port block
groups.
Display NAT444 mappings (centralized
devices in standalone mode).
Display NAT444 mappings (distributed
devices in standalone mode/centralized
devices in IRF mode).
Display NAT444 mappings (distributed
devices in IRF mode).
Clear NAT sessions (centralized devices in
standalone mode).
Clear NAT sessions (distributed devices in
standalone mode/centralized devices in IRF
mode).
Clear NAT sessions (distributed devices in IRF
mode).

NAT configuration examples

Outbound one-to-one static NAT configuration example

Network requirements
Configure static NAT to allow the host at 10.110.10.8/24 to access the Internet.
Figure 64 Network diagram
Configuration procedure
# Specify IP addresses for the interfaces on the router. (Details not shown.)
# Configure a one-to-one static NAT mapping between the private address 10.110.10.8 and the
public address 202.38.1.100.
<Router> system-view
[Router] nat static outbound 10.110.10.8 202.38.1.100
Command
display nat statistics [ summary ] [ slot slot-number ]
display nat statistics [ summary ] [ chassis
chassis-number slot slot-number ]
display nat outbound port-block-group
display nat port-block-group [ group-id ]
display nat port-block { dynamic [ ds-lite-b4 ] | static }
display nat port-block { dynamic [ ds-lite-b4 ] | static }
[ slot slot-number ]
display nat port-block { dynamic [ ds-lite-b4 ] | static }
[ chassis chassis-number slot slot-number ]
reset nat session
reset nat session [ slot slot-number ]
reset nat session [ chassis chassis-number slot
slot-number ]
