Step
2. Enter interface view.
3. Enable the DHCP relay agent.
4. Return to system view.
5. Create a DHCP relay
address pool and enter its
view.
6. Specify gateway addresses
for the clients matching the
relay address pool.
7. Specify DHCP servers for
the relay address pool.
8. Return to system view.
9. Enable the DHCP smart
relay feature.

Displaying and maintaining the DHCP relay agent

Execute display commands in any view and reset commands in user view.
Task
Display information about DHCP servers on an
interface.
Display Option 82 configuration information on the
DHCP relay agent.
Display relay entries on the DHCP relay agent.
Display packet statistics on the DHCP relay agent.
Display MAC address check entries on the DHCP
relay agent.
Clear relay entries on the DHCP relay agent.
Command
interface interface-type
interface-number
dhcp select relay
quit
dhcp server ip-pool pool-name
gateway-list ip-address&<1-64>
[ export-route ]
remote-server
ip-address&<1-8>
quit
dhcp smart-relay enable
Command
display dhcp relay server-address [ interface
interface-type interface-number ]
display dhcp relay information [ interface
interface-type interface-number ]
display dhcp relay client-information [ interface
interface-type interface-number | ip ip-address
[ vpn-instance vpn-instance-name ] ]
display dhcp relay statistics [ interface
interface-type interface-number ]
display dhcp relay check mac-address
reset dhcp relay client-information [ interface
interface-type interface-number | ip ip-address
82
Remarks
N/A
By default, an interface operates in
the DHCP server mode when DHCP
is enabled.
N/A
By default, no DHCP relay address
pool exists.
This command is the same for
creating DHCP address pools on a
DHCP server. However, the relay
address pool names are not
necessarily the same as the server
address pool names.
By default, the relay address pool
does not have any gateway
addresses.
By default, the relay address pool
does not have any DHCP server IP
addresses.
You can specify a maximum of eight
DHCP servers for one relay address
pool for high availability. The relay
agent forwards DHCP-DISCOVER
and DHCP-REQUEST packets to all
DHCP servers in the relay address
pool.
N/A
By default, the DHCP smart relay
feature is disabled.
