Configuring hub groups

Hub groups apply to large ADVPN networks. You can classify spokes to different hub groups, and
specify one or more hubs for each group.
When a VAM client registers with the VAM server, the VAM server selects a hub group for the client
as follows:
1. The server matches the private address of the client against the private addresses of hubs in
different hub groups in lexicographic order.
2. If a match is found, the server assigns the client to the hub group as a hub.
3. If no match is found, the server matches the client's private address against the private
addresses of spokes in different hub groups in lexicographic order.
4. If a match is found, the server assigns the client to the hub group as a spoke.
5. If no match is found, the registration fails.
The VAM server only assigns hub information in the matching hub group to the client. The client only
establishes permanent ADVPN tunnels to the hubs in the matching hub group.
Creating a hub group
Step
1. Enter system view.
2. Enter ADVPN domain view.
3. Create a hub group and
enter hub group view.
Configuring hub private addresses in a hub group
A hub group must have at least one hub private address.
To configure hub private addresses in the hub group:
Step
1. Enter system view.
2. Enter ADVPN domain view.
3. Enter hub group view.
4. Configure a hub private
address.
Command
system-view
vam server advpn-domain
domain-name [ id domain-id ]
hub-group group-name
Command
system-view
vam server advpn-domain
domain-name [ id domain-id ]
hub-group group-name
•
Configure a hub private IPv4
address:
hub private-address
private-ip-address
[ public-address
{ public-ip-address |
public-ipv6-address }
[ advpn-port port-number ] ]
•
Configure a hub private IPv6
address:
hub ipv6 private-address
private-ipv6-address
[ public-address
{ public-ip-address |
public-ipv6-address }
[ advpn-port port-number ] ]
364
Remarks
N/A
N/A
By default, no hub group exists.
Remarks
N/A
N/A
N/A
Use either command.
By default, no hub private
address is configured.
