Displaying and maintaining WAAS

Execute display commands in any view and reset commands in user view.
Task
Display WAAS class configuration.
Display WAAS policy configuration.
Display WAAS session information
(centralized devices in standalone
mode).
Display WAAS session information
(distributed devices in standalone
mode/centralized devices in IRF mode).
Display WAAS session information
(distributed devices in IRF mode).
Display DRE statistics (centralized
devices in standalone mode).
Display DRE statistics (distributed
devices in standalone mode/centralized
devices in IRF mode).
Display DRE statistics (distributed
devices in IRF mode).
Display the global WAAS status.
Display autodiscovered blacklist
information (centralized devices in
standalone mode).
Display autodiscovered blacklist
information (distributed devices in
standalone mode/centralized devices in
IRF mode).
Display autodiscovered blacklist
information (distributed devices in IRF
mode).
Clear the DRE data dictionary.
Clear DRE statistics.
Clear all blacklist entries.

WAAS configuration examples

Predefined WAAS policy configuration example

Network requirements
As shown in
The host downloads data from the server. Examine the optimization effect by comparing DRE
statistics for the first download and second download.
Figure 166, apply the predefined WAAS policy on Router A and Router B.
Command
display waas class [ class-name ]
display waas policy [ policy-name ]
display waas session { ipv4 | ipv6 } [ client-ip client-ip ]
[ client-port client-port ] [ server-ip server-ip ] [ server-port
server-port ] [ peer-id peer-id ] [ verbose ]
display waas session { ipv4 | ipv6 } [ client-ip client-ip ]
[ client-port client-port ] [ server-ip server-ip ] [ server-port
server-port ] [ peer-id peer-id ] [ verbose ] [ slot slot-number ]
display waas session { ipv4 | ipv6 } [ client-ip client-ip ]
[ client-port client-port ] [ server-ip server-ip ] [ server-port
server-port ] [ peer-id peer-id ] [ verbose ] [ chassis
chassis-number slot slot-number ]
display waas statistics dre [ peer-id peer-id ]
display waas statistics dre [ peer-id peer-id ] [ slot
slot-number ]
display waas statistics dre [ peer-id peer-id ] [ chassis
chassis-number slot slot-number ]
display waas status
display waas tfo auto-discovery blacklist { ipv4 | ipv6 }
display waas tfo auto-discovery blacklist { ipv4 | ipv6 } [ slot
slot-number ]
display waas tfo auto-discovery blacklist { ipv4 | ipv6 }
[ chassis chassis-number slot slot-number ]
reset waas cache dre [ peer-id peer-id ]
reset waas statistics dre [ peer-id peer-id ]
reset waas tfo auto-discovery blacklist
