3. VLT AQUA Selection
3
1)
IMPORTANT! The label MUST be placed on the LCP frame as shown (UL approved).
Warning Dual supply
How to add the MCB 105 option:
See mounting instructions in the beginning of section
The power to the live part connections on relay terminals must be disconnected.
Do not mix live parts (high voltage) with control signals (PELV).
Select the relay functions in par. 5-40 [6-8], 5-41 [6-8] and 5-42 [6-8].
NB! (Index [6] is relay 7, index [7] is relay 8, and index [8] is relay 9)
Do not combine low voltage parts and PELV systems.
68
A2-A3-B3
Options and Accessories
MG.20.N3.02 - VLT
A5-B1-B2-B4-C1-C2-C3-C4
®
is a registered Danfoss trademark
®
VLT
AQUA Drive Design Guide
