Table 5.3: Non UL fuses 200 V to 500 V
1) Max. fuses - see national/international regulations for selecting an applicable fuse size.
UL Compliance
VLT AQUA Bussmann
200-240 V
kW Type RK1
K25-1K1 KTN-R10
1K5 KTN-R15
2K2 KTN-R20
3K0 KTN-R25
3K7 KTN-R30
5K5 KTN-R50
7K5 KTN-R50
11K KTN-R60
15K KTN-R80
18K5 KTN-R125
22K KTN-R125
30K FWX-150
37K FWX-200
45K FWX-250
Table 5.4: UL fuses 200 - 240 V
Max. fuse size
16A 1
16A 1
1
25A
1
25A
35A 1
50A 1
63A 1
1
63A
80A 1
125A 1
1
125A
160A 1
1
200A
1
250A
63A 1
63A 1
63A 1
63A 1
1
80A
1
100A
1
125A
160A 1
250A 1
250A 1
Bussmann Bussmann SIBA
Type J Type T Type RK1
JKS-10 JJN-10 5017906-010
JKS-15 JJN-15 5017906-015
JKS-20 JJN-20 5012406-020
JKS-25 JJN-25 5012406-025
JKS-30 JJN-30 5012406-030
JKS-50 JJN-50 5012406-050
JKS-60 JJN-60 5012406-050
JKS-60 JJN-60 5014006-063
JKS-80 JJN-80 5014006-080
JKS-150 JJN-125 2028220-125
JKS-150 JJN-125 2028220-125
- - 2028220-150
- - 2028220-200
- - 2028220-250
®
MG.20.N3.02 - VLT is a registered Danfoss trademark
Voltage
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
200-240 V
380-480 V
380-480 V
380-480 V
380-480 V
380-480 V
380-480 V
380-480 V
380-480 V
380-480 V
380-480 V
Ferraz-
Littel fuse
Shawmut
Type RK1 Type CC
KLN-R10 ATM-R10
KLN-R15 ATM-R15
KLN-R20 ATM-R20
KLN-R25 ATM-R25
KLN-R30 ATM-R30
KLN-R50 -
KLN-R60 -
KLN-R60
KLN-R80
KLN-R125
KLN-R125
L25S-150
L25S-200
L25S-250
5. How to Install
Type
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type aR
type aR
5
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type gG
type aR
type aR
Ferraz-
Shawmut
Type RK1
A2K-10R
A2K-15R
A2K-20R
A2K-25R
A2K-30R
A2K-50R
A2K-50R
A2K-60R
A2K-80R
A2K-125R
A2K-125R
A25X-150
A25X-200
A25X-250
