CONTROL COMMAND
D Command table (continued)
Cmd. Sub cmd. Data
15 15 0000 to
0255
16 0000 to
0255
16 02 00
01
02
12 00
01
02
22 00
01
32 00
01
02
03
40 00
01
41 00
01
42 00
01
43 00
01
44 00
01
45 00
01
46 00
01
47 00
01
02
48 00
01
4F 00
01
50 00
01
19 00
1A 00 see p. 000 Send/read memory contents
01 see p. 000 Send/read band stacking register contents
02 see p. 000 Send/read memory keyer contents
03 00 to 49 Send/read the selected filter width
04 00 to 13 Send/read the selected AGC time constant
05 0001 see p. 000 Send/read HPF/LPF setting for SSB RX audio
0002 00 to 10 Send/read SSB RX Tone (Bass) level
0003 00 to 10 Send/read SSB RX Tone (Treble) level
0004 see p. 000 Send/read HPF/LPF setting for AM RX audio
0005 00 to 10 Send/read AM RX tone (Bass) level
0006 00 to 10 Send/read AM RX Tone (Treble) level
0007 see p. 000 Send/read HPF/LPF setting for FM RX audio
0008 00 to 10 Send/read FM RX tone (Bass) level
0009 00 to 10 Send/read FM RX Tone (Treble) level
0010 see p. 000 Send/read HPF/LPF setting for CW RX audio
0011 see p. 000 Send/read HPF/LPF setting for RTTY RX audio
0012 see p. 000 Send/read HPF/LPF setting for PSK RX audio
0013 00 to 10 Send/read SSB TX Tone (Bass) level
0014 00 to 10 Send/read SSB TX Tone (Treble) level
152
Description
Read VD meter
(0152=10, 0181=13, 0212=16)
Read ID meter
(0000=0, 0097=10, 0241=25)
Preamp OFF
Preamp 1 ON
Preamp 2 ON
AGC FAST selection
AGC MID selection
AGC SLOW selection
Noise blanker OFF
Noise blanker ON
Audio peak filter OFF
Audio peak filter WIDE ON
(320 is selected when SHARP APF is set)
Audio peak filter MID ON
(160 is selected when SHARP APF is set)
Audio peak filter NAR ON
(80 is selected when SHARP APF is set)
Noise reduction OFF
Noise reduction ON
Auto notch function OFF
Auto notch function ON
Repeater tone OFF
Repeater tone ON
Tone squelch OFF
Tone squelch ON
Speech compressor OFF
Speech compressor ON
Monitor function OFF
Monitor function ON
VOX function OFF
VOX function ON
BK-IN function OFF
SEMI BK-IN function ON
Full BK-IN function ON
Manual notch function OFF
Manual notch function ON
Twin peak filter OFF
Twin peak filter ON
Dial lock function OFF
Dial lock function ON
Reads the transceiver ID
( SSB, CW, PSK: 00=50 Hz, 40=3600 Hz;
RTTY: 00=50 Hz, 31=2700 Hz;
AM: 00=200 Hz, 49=10 kHz)
(00=OFF, 01=0.1/0.3 sec., 13=6.0/8.0 sec.)
(00=–5, 10=+5)
(00=–5, 10=+5)
(00=–5, 10=+5)
(00=–5, 10=+5)
(00=–5, 10=+5)
(00=–5, 10=+5)
(00=–5, 10=+5)
(00=–5, 10=+5)
Cmd. Sub cmd. Data
1A 05 0015 00 to 10 Send/read AM TX Tone (Bass) level
(00=–5, 10=+5)
0016 00 to 10 Send/read AM TX Tone (Treble) level
(00=–5, 10=+5)
0017 00 to 10 Send/read FM TX Tone (Bass) level
(00=–5, 10=+5)
0018 00 to 10 Send/read FM TX Tone (Treble) level
(00=–5, 10=+5)
0019 see p. 000 Send/read SSB TX bandwidth for WIDE
0020 see p. 000 Send/read SSB TX bandwidth for MID.
0021 see p. 000 Send/read SSB TX bandwidth for NARROW
0022 0000 to Send/read DRIVE gain
0255 (0000=0%, 0255=100%)
0023 0000 to Send/read speech level
0255 (0000=0%, 0255=100%)
0024 0000 to Send/read CW side tone level
0255 (0000=0%, 0255=100%)
0025 00 CW side tone gain limit OFF
01 CW side tone gain limit ON
0026 0000 to Send/read beep gain
0255 (0000=0%, 0255=100%)
0027 00 Beep gain limit OFF
01 Beep gain limit ON
0028 00 Squelch mute effect OFF for audio output
from USB-B connector
01 Squelch mute effect ON for audio output
from USB-B connector
0029 0000 to Send/read modulation level for audio input to
0255 USB-B connector (0000=0%, 0255=100%)
0030 00 [MIC] selection for MOD input connector dur-
ing DATA OFF
01 [ACC] selection for MOD input connector
during DATA OFF
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA OFF
03 [USB] selection for MOD input connector dur-
ing DATA OFF
0031 00 [MIC] selection for MOD input connector dur-
ing DATA1
01 [ACC] selection for MOD input connector
during DATA1
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA1
03 [USB] selection for MOD input connector dur-
ing DATA1
0032 00 [MIC] selection for MOD input connector dur-
ing DATA2
01 [ACC] selection for MOD input connector
during DATA2
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA2
03 [USB] selection for MOD input connector dur-
ing DATA2
0033 00 [MIC] selection for MOD input connector dur-
ing DATA3
01 [ACC] selection for MOD input connector
during DATA3
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA3
03 [USB] selection for MOD input connector dur-
ing DATA3
0034 00 Lead selection for SEND relay type
01 MOS-FET selection for SEND relay type
0035 00 Auto selection for external meter output
01 S (receiving signal strength) selection for ex-
ternal meter output
02 Po (TX output power) selection for external
meter selection
03 SWR selection for external meter output
04 ALC selection for external meter output
05 COMP selection for external meter output
06 Vd selection for external meter output
07 Id selection for external meter output
0036 0000 to Send/read external meter output level
0255 (see p. 000)
Description
