Keyboard [F-1]–[F-4] (VOICE)
Sets the voice message transmission capability ON
and OFF when one of [F-1]−[F-4] key of the key-
board that is connected to the [USB] (A) connector
on the front panel is pushed. (default: OFF)
Keyboard [F-1]–[F-4] (KEYER)
Sets the keyer memory transmission capability ON
and OFF when one of [F-1]−[F-4] key of the key-
board that is connected to the [USB] (A) connector
on the front panel is pushed. (default: OFF)
CI–V Baud Rate
Sets the CI-V data transfer rate. 300, 1200, 4800,
9600, 19200 bps and "Auto" are available.
(default: Auto)
When "Auto" is selected, the baud rate is auto-
matically set according to the data rate of connected
controller.
CI–V Address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-7600's address is 7Ah.
When 2 or more IC-7600's are connected to an op-
tional CT-17 -
CI V LEVEL CONVERTER
dial to select a different address for each IC-7600;
the range is 01h to 7Fh.
CI–V Transceive
Transceive operation is possible with the IC-7600
connected to other Icom HF transceivers or receivers.
When "ON" is selected, changing the frequency,
operating mode, etc. on the IC-7600 automatically
changes those of connected transceivers (or receiv-
ers) and vice versa.
USB Serial Function
Select [USB] connector output data format from CI-V
and Decode.
OFF
• ON
• OFF
OFF
• ON
• OFF
Auto
7Ah
, rotate the main
ON
CI-V
• CI-V
• Decode : Outputs decoded contents in ASCII code
SET MODE
: Pushing one of [F-1]−[F-4] key of the con-
nected keyboard transmits the desired
voice message contents during a phone
mode operation.
: [F-1]−[F-4] key of the connected key-
board does not function.
: Pushing one of [F-1]−[F-4] key of the con-
nected keyboard transmits the desired
keyer memory contents during CW mode
operation.
: [F-1]−[F-4] key of the connected key-
board does not function.
: Outputs data in CI-V format. (default)
format.
