SSB TBW (WIDE)
Sets the transmission passband width to a wide
setting by changing the lower and higher cut-off fre-
quencies.
SSB TBW (MID)
Sets the transmission passband width to a middle
setting by changing the lower and higher cut-off fre-
quencies.
SSB TBW (NAR)
Sets the transmission passband width to a narrow
setting by changing the lower and higher cut-off fre-
quencies.
Drive Gain
Sets the drive gain level from 0% to 100% in 1%
steps. (default: 50%)
While talking into the microphone, keying down or
transmitting, rotate the main dial so that the ALC
meter reading is between 30% to 50% of the ALC
scale. (p. ??)
The drive gain is active for all modes other than SSB
mode with speech compressor OFF.
Speech Level
Sets the voice synthesizer audio output level from
0% to 100% in 1% steps. (default: 50%)
Side Tone Level
Sets the side tone output level from 0% to 100% in
1% steps. (default: 50%)
Side Tone Level Limit
Turns the side tone output level limiting capability
ON and OFF. (default: ON)
When this item is set to ON, the CW side tone is
linked to the [AF] control until rotation of the [AF]
control reaches to the specified level—further rota-
tion will not increase the volume of the CW side
tones.
100 – 2900
• Lower freq. : 100 (default), 200, 300 and 500 Hz
• Higher freq. : 2500, 2700, 2800 and
2900 Hz (default)
300 – 2700
• Lower freq. : 100, 200, 300 (default) and 500 Hz
• Higher freq. : 2500, 2700 (default), 2800
and 2900 Hz
500 – 2500
• Lower freq. : 100, 200, 300 and 500 Hz (default)
• Higher freq. : 2500 (default), 2700, 2800
and 2900 Hz
50 %
50 %
50 %
ON
• ON : CW side tone level is limited with the [AF]
control.
• OFF : CW side tone level is linked to the [AF] con-
trol.
10
SET MODE
