Icom IC-718 Instruction Manual page 50

10
SET MODE
Others set mode (Continued)
CW Normal Side
Selects the side band used to receive CW in CW
normal mode. (default: LSB)
APF Type
Select audio filter shape for APF from SOFT and
SHARP. (default: SOFT)
External Keypad (VOICE)
Sets the external keypad for voice message trans-
mission capability ON and OFF. (default: OFF)
See page ?? for the equivalent circuit of an external
keypad and connection.
External Keypad (KEYER)
Sets the external keypad for keyer memory trans-
mission capability ON and OFF. (default: OFF)
See page ?? for the equivalent circuit of an external
keypad and connection.
External Keypad (RTTY)
Sets the external keypad for RTTY TX memory
transmission capability ON and OFF. (default: OFF)
See page ?? for the equivalent circuit of an external
keypad and connection.
External Keypad (PSK)
Sets the external keypad for PSK TX memory trans-
mission capability ON and OFF. (default: OFF)
See page ?? for the equivalent circuit of an external
keypad and connection.
133
LSB
SOFT
• SOFT : Soft filter shape makes distinguishing
noise and signals easier. The audio filter
width is related to the CW pitch setting.
• SHARP : Sharp filter shape rejects interfering sig-
nals more aggressively.
OFF
• ON : Pushing one of external keypad switches,
transmits the desired voice message con-
tents during a phone mode operation.
• OFF : External keypad does not function.
OFF
• ON : Pushing one of external keypad switches,
transmits the desired keyer memory con-
tents during CW mode operation.
• OFF : External keypad does not function.
OFF
• ON : Pushing one of external keypad switches,
transmits the desired RTTY TX memory
contents during RTTY mode operation.
• OFF : External keypad does not function.
OFF
• ON : Pushing one of external keypad switches,
transmits the desired PSK TX memory
contents during PSK mode operation.
• OFF : External keypad does not function.
