Icom IC-718 Instruction Manual page 2

4
RECEIVE AND TRANSMIT
Break-in function
<MODE> CW
The break-in function is used in CW mode to auto-
matically toggle the transceiver between transmit and
receive when keying. The IC-7600 is capable of full
break-in or semi break-in.
D Semi break-in operation
During semi break-in operation, the transceiver imme-
diately transmits when keying, then returns to receive
after a pre-set delay time has passed from when you
stop keying.
q Push [CW] to select CW or CW-R mode.
w Push [BK-IN] (MF6) once or twice to turn the semi
break-in function ON.
• "BKIN" appears.
e Rotate [BK-IN DELAY] to set the break-in delay
time (the delay from transmit to receive).
When using a paddle, rotate [KEY SPEED] to
adjust the keying speed.
D Full break-in operation
During full break-in operation, the transceiver imme-
diately transmits when keying, then returns to receive
after you stop keying.
q Push [CW] to select CW or CW-R mode.
w Push [BK-IN] (MF6) once or twice to turn the full
break-in function ON.
• "F-BKIN" appears.
When using a paddle, rotate [KEY SPEED] to
adjust the keying speed.
85
[BK-IN]
CW
[BK-IN DELAY] [KEY SPEED]
[BK-IN]
CW
[KEY SPEED]
Appears
Appears
