DocuCutter 545
The Service Modes are described in Table 2.
HELP CODE
H-00 ROM version indication
H-01 Total cut counter
H-02 Total feed counter
H-03 P.P.S.1 check
H-04 P.P.S.2 check
H-05 P.P.S.3 check
H-06 P.P.S.4 check
H-07 P.P.S.5 check
H-08 Sensor & switch check
H-09 DIP SW status check
H-10 Feed motor check
H-11 Feed solenoid check
H-12 Left margin slitter check
H-13 Right margin slitter check
H-14 Left center slitter check
H-15 Right center slitter check
H-16 OP1 slitter check
H-17 Main motor check
H-18 Score check
H-19 Cutter check
H-20 Slitter blade drive check
H-21 LED check
H-22 CCD performance check
H-23 Total score counter
H-24 Slitter position adjustment
H-25 RAM initialize
H-26 Score distance adjustment
H-27 P.P.S.2 & CCD distance adjustment
H-28 OP2 slitter check (Option slitter 2)
H-29 Elevator check (Optional AF-100)
H-30 Fan Check (Optional AF-100)
H-31 Solenoid & Feed check (Optional AF-100)
H-32 Feeder Total check (Optional AF-100)
H-33 SPEED UP – Prevents slitters from returning home
while in REG mark correction mode.
