DocuCutter DC-545 Service Mode

42
DocuCutter 545
Entering the Service Mode in the DocuCutter DC-545
enables you to perform a variety of diagnostic tests.
NOTE The information provided here is also available in General
Procedure GP-4 of the DocuCutter DC-545 Field Service
Manual. It is presented in this document for reference
purposes only.
The procedure for entering the Service Mode follows:
1. If the machine is already powered on, power off the
machine.
2. While depressing the STOP button, power on the
machine. A buzzer will sound to indicate you are
entering the Service Mode.
3. Press the <+> or <-> buttons to scroll through the
available Service Mode diagnostic selections.
4. When you locate the appropriate Service Mode
diagnostic selection, press the START button.
To exit the Service Mode, press the STOP button and
switch the power off.
