DocuCutter 545

Cutting

The DocuCutter DC-545 uses an integrated Cutter to
produce a cut (or multiple cuts) perpendicular to the paper
path, as determined by the program data. The Cutter
specifically enables lead and trail edge cuts so custom
finished sizes and full bleed documents are obtainable. It
also enables multiple cut applications such as business
cards to be produced in a single pass. Cutting is
accomplished using the components listed below:
• A high torque DC motor with a self-contained torque
enhancing transmission
• Long life (2,000,000 cuts), replaceable, precision
upper cutting blade
Cutter Construction
The Cutter Unit consists of a movable, precisely beveled,
Upper Cutting Blade and a counter-cutting surface. Much
like a pair of scissors, the two pieces working together
produce a very fine cut. The design provides for high
performance with long life characteristics.
